• 2nd Gen 8K/e-shiftX 8K60p/4K120p home projector
• Best-in-class dark-room home theater performance
• Industry’s highest native contrast with the 3rd Gen 0.69-inch 4K D-ILA device and wire-grid optical engine
• Native Contrast Ratio of 150,000:1, Dynamic contrast level of ∞:1 (infinity to 1)
• 18-element, 16-group all-glass lens featuring full aluminum lens barrel
• 3,300 lumens light output
• BLU-Escent Laser light source with longevity of 20,000 hours
• HDR10+, Theater Optimizer, FILMMAKER MODE™, ISF C3 mode,  2nd Gen Frame Adapt HDR
• Made in Japan

The JVC DLA-NZ900 is a cutting-edge 8K home theater projector designed to deliver an exceptional cinematic experience.

Featuring JVC’s advanced D-ILA technology and native 4K resolution, it offers stunning clarity, contrast, and vibrant color reproduction.

With a high dynamic range (HDR) and a wide color gamut, the NZ900 brings movies, sports, and games to life with remarkable detail and depth.

Its versatile connectivity options and intuitive setup make it perfect for both casual viewers and serious home theater enthusiasts.



JVC’s proprietary 8K/e-shiftX, which is a combination of “e-shift technology” – a high-resolution display technology that doubles the resolution by shifting a pixel by 0.5 pixels in four directions up, down, left, and right – and “0.69-inch native 4K D-ILA devices” has made significant progress as the second generation 8K/e-shiftX.

The latest version features JVC’s newest 8K scaling engine that drastically improves the projector’s sharpness and detail across a wide range of content, including 8K (8192 x 4320 pixels) sources.

The Frame Adapt HDR function, which uses a proprietary algorithm to instantaneously analyze the maximum brightness of any HDR10 content per scene or per frame and perform real-time tone mapping to optimal dynamic range for video projection, has evolved into the second generation (Gen2).

The algorithm for tone mapping has been fully reexamined to achieve HDR images with higher definition. Furthermore, the proprietary algorithm for tone curve selection has also been improved to reproduce HDR images that are brighter, more colorful and have a wider dynamic range.

The new D-ILA projector boasts the industry’s highest native contrast with the Gen3 0.69-inch 4K D-ILA device and wire-grid optical engine, however in combination with the dynamic laser light control, which analyzes the incoming video signal to automatically control the amount of outgoing laser light, a dynamic contrast level of ∞:1 (infinity to 1) can be achieved in scenes with pitch blackness by completely shutting off the light source.

As a result, images brimming with reality that are closer to human perception can be produced. Likewise, the new algorithm enables laser control with greater precision to meet the user’s preferences.

The high-end DLA-NZ900 is equipped with an 18-element, 16-group all-glass lens featuring a full aluminium lens barrel. To project high resolution 8K images to every corner of the screen, the projector incorporates five ED lenses calibrated for differences in the R/G/B refractive index to reduce chromatic aberration and colour fringing when lens shift kicks in to deliver precise reproduction of 4K- or 8K-resolution projection.

This D-ILA models support a variety of inputs including full 48Gbps 8K60p. By adopting LSIs developed with the latest technology, it is now possible to process four times the amount of information from input to D-ILA device instantly and correctly display 8K signals.

As a result, users can enjoy stable high-quality 8K images at all times. Also, using 4K120p input with the Low Latency Mode further improves response to the player’s rapid operations, making it effective for displaying high frame-rate gaming content on large screens.

Another essential aspect of projectors lies in their light source. The DLA-NZ series adopts JVC’s original laser light source “BLU-Escent Laser” to achieve exceptional peak brightness of 3,300 lumens on the DLA-NZ900, with longevity of 20,000 hours. When compared to the first-generation laser projector*, the projectors’ brightness per effective wattage has improved 1.9-fold, which, as a result, also contributes to saving power through improved power efficiency.

When it comes to reproducing the rich video information of HDR content, including the extended brightness range, BT.2020 wide color gamut and 10-bit gradation, rely on the new D-ILA projectors.

Both models support all HDR formats including HDR10 for Blu-ray and streaming, HLG for broadcasting, and the HDR10+ with dynamic metadata compatibility. The projectors’ improvements for higher brightness and contrast have helped to achieve a wider dynamic range, allowing users to enjoy an immersive experience with HDR images full of reality.

USB Back-up function saves the settings on the main unit menu to a commercially available USB flash drive. Professional adjustments can be saved or backed up in advance to undo unintended adjustments by children or family members.

Flexible installation is made possible thanks to the wide lens-shift function. As described in the diagram, wide shift ranges are offered vertically and horizontally to help deliver natural projected images without distortion.

FILMMAKER MODE™ that faithfully recreates the creator’s intentions

FILMMAKER MODE™ was developed by the UHD Alliance, an organization of Hollywood movie studios, TV studios, content distributors, consumer electronics manufacturers, and device developers, with the aim of faithfully reproducing the filmmakers’ intentions in the home.

When using this mode, picture quality adjustment functions such as frame interpolation and noise reduction are turned off, and the color temperature is set to D65 (6500K), allowing users to enjoy movies and documentaries with picture quality that is faithful to the original master.

HIGHLIGHTS:

• 2nd Generation 8K/e-shiftX technology reproduces 8K image quality
• New BLU-Escent Laser Light Source
• 3rd Generation 0.69-inch 4K D-ILA (4096 x 2160) device x 3.
• High brightness of 3,300 lm provides vibrant and dynamic images
• Native Contrast Ratio of 150,000:1 translates to a spectacular Dynamic Contrast Ratio of ∞ :1
• 2x HDMI (48 Gbps, HDCP 2.3) inputs, supporting 8K60P and 4K120P input signals
• HDR10+ contains the metadata of the producer’s intentions for each scene, and with such data, the projector is able to automatically reproduce images as the creator intended.
• Auto Tone Mapping function automatically adjusts settings for optimum HDR10 image quality.
• 18-element, 16-group all-glass 100mm diameter high-quality lens.
• Wide Color Gamut above exceeds DCI/P3 spec creating saturated, beautiful images that come to life.
• Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles.

• Frame Adapt HDR dynamically tone maps any HDR10 content frame-by-frame or scene-by-scene and automatically performs adjustment to achieve optimal images close to reality as seen by human eyes. As a part the Frame Adapt HDR, the projector offers improved gamma processing accuracy from 12- to 18-bit equivalent to reproduce smoother and finer gradation. Additional Frame Adapt HDR picture modes allows for optimum playback with the widest variety of lighting conditions or theater environments.
• Theater Optimizer function, which works in Frame Adapt HDR mode, offers optimum HDR images by analyzing usage environments using the screen size and gain information and intelligently adjusts tone mapping. HDR Quantizer with New Auto (Wide) level mode provides brighter/more dynamic HDR images. *​
• FILMMAKER MODE™ that faithfully recreates the creator’s intentions.*​
• Eight settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, and Aspect; stored installation modes for various environments can be called up.
• ISF C3 (Certified Calibration Controls) mode to reproduce excellent picture quality optimized for specific environments
• Auto-Calibration Function using an optical sensor.



Device
D-ILA Technology	Yes
Chip Type	3rd Generation 0.69-inch 4K D-ILA device
Native Resolution	4096 x 2160
Number Of Chips	3
8K/e-shiftX	Yes
Display Resolution	8192 x 4320
Light Sourcce
Laser	Yes
Type	New BLU-Escent Laser Diode
Life Time (Standard Mode)	20000 hours
Brightness	3300 lm
Dynamic Contrast	Infinity : 1
Native Contrast	150000 : 1
Dynamic Light Power control	Yes
Modes	Low, High, Balance, Off
Manual Aperture	Yes
Range	-15 (stops down) to 0 (opens up)
DCI-P3 Color Gamut	Yes
100% REC 709	Yes
Color Bit Depth	12 bit
ISFccc Certification	Yes
HDR
HDR10	Yes
HDR10+	Yes
Frame Adapt HDR	Yes
Theater Optimizer	Yes
HLG	Yes
Auto Tone Mapping	Yes
Mastering Info Display	Yes
Info data	MaxCLL, MaxFALL and DML
Deep Black Tone Control	Yes
Lens
Zoom	2 x
Throw Ratio	1.35-2.75:1
Diameter	100mm
Material	All-glass
Build	18-element, 16-group in full aluminium lens barrel.
Lens Shift	Yes
Range Horizontal	± 43 %
Range Vertical	± 100 %
Motorized Zoom	Yes
Motorized Shift	Yes
Motorized Focus	Yes
Projection Display size (diagonal)	60 – 300 inch
Memory Function	Yes
Number of user presets	10
Lens Cover	Yes
HDMI
HDMI	Yes
Number of Inputs	2
Data Rate	48 Gbps
HDCP Version	2.3
8K60P signal input	Yes
4K120p signal input	Yes
4K60P signal input	Yes
Video Signal range	480p, 576p, 720p 60/50, 1080i 60/ 50, 1080p 120/ 100/ 60/ 50/ 30/ 25/ 24, 3840 x 2160p 120/ 100/ 60/ 50/ 30/ 25/ 24, 4096 x 2160p 120/ 100/ 60/ 50/ 30/ 25/ 24, 7680 x 4320p 60/ 50/ 30/25 /24
PC Signal range	VGA / SVGA / XGA / WXGA / WXGA+ / SXGA / WSXGA+ / UXGA / WUXGA / WQHD (60) / WQHD (120)
Input Level Adjustment	Auto / Standard (16-235) / Enhanced (0-255) / Super White (16-255)
Color Space Range	Auto/ YCbCr444 / YCbCr422 / RGB
EDID Modes	A , B and C (older hardware may need to use B settings)
Connections
Trigger out	Yes
Connector	Mini-Jack (3,5mm)
Power	DC 12V / 100mA
3D Synchro	Yes
Connector	Mini DIN 3-pin
LAN	Yes
Connector	RJ45
RS-232	Yes
Connector	D-sub 9-pin
Service	Yes
Connector	USB (Type A) for firmware update or backup
3D
3D Capability	Yes
3D Versions	Frame Packing, Side-by-Side, Top & Bottom
Frame Packing Resolutions	720p 60/50, 1080p 24
Side-by-Side Resolutions	720p 60/50, 1080p 60/50/24, 1080i 60/50
Top & Bottom Resolution	720p 60/50, 1080p/24
3D Emitter (Optional)	Yes, PK-EM2
3D Glasses (Optional)	Yes, PK-AG3
Picture settings
Picture Modes	Natural, Cinema, Film, Vivid, HDR10+, Frame Adapt HDR, HDR10, HLG, 6 User modes
Color Temperatures	Xenon 1, Xenon 2, 5500K, 6500K, 7500K, 9300K, High Bright, HDR10+, HDR10, HLG, Custom 1, Custom 2
Gamma Processing Depth	12 bit
Gamma Adjust	HDR (Auto), HDR(PQ), HDR(HLG), 2.2, 2.4, 2.6, Cinema 1, Cinema 2, Film 1, Film 2, 3 Custom modes
Color Management	6-Axis adjustable CMS
MPC	Yes
Filmmaker Mode	Yes
Low Latency Mode	Yes
Clear Motion Drive	Yes
Motion Enhance	Yes
Auto Calibration	Yes
Optional Probe needed	Yes
Installation Mode	Yes
Number of modes	10
Included settings	Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, and Aspect
Anamorphic Modes	4 Modes (A, B, C, D)
Control4 SDDP	Yes
Power & Environment
Power Requirement	AC100-240V, 50/60Hz
Projector in Use	440W
Standby	Eco-mode: 0.3W
Network Standby	1.5W (LAN)
Fan Noise	24 dB
Eco Mode	Yes
Standby Timer	Yes
Operating Temperature	5°C to 35°C
Operating Humidity	20% to 80%
Installation Angle	Horizontal +/- 10 degree / Vertical +/- 10 degree
Installation Height	Below 2,000 m
In the box
Remote Control	Yes, RM-MH27
Quick Guide	Yes
Power Cord	Yes
Batteries	Yes, 2 x AAA-size batteries
Dimensional & Weight
Product Dimensions (WxHxD)	19-11/16 x 9-7/32 x 20-13/16 (inch)
Product Weight	55.7 Lb

Price:  RM199,999

*1 Year Warranty

**Includes installation and ISF-Certified Calibration
